Equipment name: Microcomputer-controlled electronic universal testing machine
Product model: CMT5105
The main function of the equipment: This equipment is suitable for testing the mechanical properties of metallic materials, non-metallic materials and composite materials and analyzing and researching process performance. Equipped with corresponding tooling, it can do tensile, compression, bending, shearing, tearing, peeling, bursting, fatigue and other tests. It can automatically obtain parameters such as endurable test force value, breaking force value, elongation, tensile strength, yield strength, compressive strength, elastic modulus, shear strength, tear strength, and peel strength. At the same time, it can also realize the test of constant elongation stress, constant stress elongation, load retention and other requirements. This machine is widely used in material inspection and analysis of construction materials, aerospace, machinery manufacturing, wire and cable, rubber and plastics, automobile manufacturing, powder metallurgy, fasteners and other industries. It is used for scientific research institutions, universities, industrial and mining enterprises, and technical supervision. , The ideal testing equipment for commodity inspection and arbitration departments.
Can be tested according to: GB, ASTM, DIN, ISO, JIS, BS and other standards.
Testing machine manufacturing standard: GB/T 16491-2008 electronic universal testing machine
GB/T 228.1-2010 "Metal material room temperature tensile test method" GB/T 232-2010 "Metal material bending test method" GB/T 7314-2007 "Metal material room temperature compression test method" (Users can provide relevant test standards, No more than 5)
Product Details:
The host adopts a single-space structure, and the test space is pulled down and pressed down, and is mainly composed of a base and a frame. The base is made of cast iron, and the frame is a door structure, which is mainly composed of a bottom plate, upper, middle and lower beams and connecting light bars. The test machine has good coaxiality (<8%). The upper, middle and lower beams are made of ductile iron, and the tensile strength is up to It is 60k (600MPa), and its yield strength is 40k (400Mpa); high-strength light bars are used to fix the upper beam and the work surface to form a high-rigidity structural frame. The corrosion resistance and oxidation resistance of ductile iron exceed Cast steel. Due to the spheroidal graphite microstructure of ductile cast iron, ductile cast iron is superior to cast steel in terms of vibration reduction ability, so it is more conducive to reducing stress. This machine has beautiful appearance, good stability, high rigidity, high control accuracy, and high work efficiency. Low noise, energy saving and environmental protection.
This series of models has a variety of optional model structures, such as the following space models, pull-up and down pressure dual-space models, and up-pressure pull-down dual-space models, etc., and can be equipped with environmental boxes and high-temperature furnaces for environmental testing.
