Microcomputer controlled electronic torsion testing machine

Product model: CTT1101, CTT1201, CTT1501, CTT1102, CTT1202, CTT1502

Product Overview: Microcomputer controlled torsion testing machine is suitable for torsional performance testing of metal materials, non-metallic materials, composite materials and shaft components. The machine has the characteristics of stable and reliable operation, no pollution, wide measurement range, high resolution and high precision. Tests such as torsional failure of the material, detection of torsional shear modulus, and multi-step torque loading can be completed. Equipped with a torsion meter to measure the shear modulus, specified non-proportional torsional stress, and other static torsional mechanics performance tests

Mainly suitable for measurement and quality inspection; automotive, transmission machinery, bolt fasteners, metallurgy and iron and steel, machinery manufacturing, civil aviation, universities, scientific research laboratories, commodity inspection and arbitration, technical supervision department, building materials ceramics, petrochemical and other industries Mechanics laboratory, etc., is the ideal experimental equipment for factories, schools and scientific research units

Executive Standard

GB / T10128-2007 "Metal material torsion test method at room temperature"

JB / T9370-2007 "Technical Conditions of Torsion Testing Machine"

JJG269-2006 "Verification Regulation of Torsion Testing Machine"

GB / T2611-2007 "General Technical Requirements for Testing Machines"

Users can also provide relevant technical standards, in accordance with the standards provided by users, such as GB, ASTM, DIN, JIS, EN, etc., to achieve the control of the test mode and related data collection and processing.
