ZBC3000C series microcomputer controlled metal pendulum impact testing machine,- Pendulum impact testing machine,Jiaxing Siren Machinery Co.Ltd

Product function overview: This machine is an instrument for testing the impact resistance of metal materials under dynamic load. It can continuously perform a large number of metal impact tests. It adopts fully automated control, and the control system uses imported programmable controller (PLC). The software program controls the whole process of fetching and impact testing. Shows the impact absorption work, impact toughness, pendulum rotation angle, and print test report. The operation is simple, safe and reliable, and the working efficiency is high. This machine is equipped with a protective net cover, which provides conditions for the user's safe operation. It is an indispensable testing instrument for metal material manufacturers and quality inspection departments, and an indispensable testing instrument for new materials research by scientific research institutions.

Related implementation standards:

This machine is developed and produced according to the national standard GB / T 3808-2002 "Inspection of Pendulum Impact Testing Machine", and the impact test of metal materials is carried out according to the national standard GB / T 229-2007 "Metal Material Charpy Pendulum Test Method" Comply with JJG 145-2007 "Pendulum Impact Tester Verification Regulation". If you change the structure and replace the related parts, you can meet the requirements of the international standards such as American Standard, European Standard ASTM E23, EN 10045, ISO 148, ISO 83 and so on.
